تحبيب شديد التحمل للبلاستيك الصلب الضخم
كسارة بلاستيكية صلبة شديدة التحمل مع فتحة تغذية كبيرة جدًا
High-capacity granulator machines for large rigid plastics such as
pallets, drums, crates, car seats, and bulky molded parts. Choose from powerful models delivering
roughly 300 kg/h to 1200 kg/h depending on material and screen size.
مصمم لإنتاج حبيبات بلاستيكية صلبة كبيرة الحجم
This series is designed for processors who need to granulate oversized
rigid parts without relying on undersized standard granulators that jam, vibrate, or wear too
quickly.
دوار ذو قطع على شكل حرف V مفتوح على نطاق واسع للتغذية الضخمة
The open rotor with staggered V-cut claw blades improves bite, cutting force, and discharge flow
when processing large rigid plastic articles such as pallets, drums, and crates.
شفرات من فولاذ الأدوات D2 الممتاز
Heat-treated D2 blades support long cutting cycles, repeated sharpening, and dependable
performance on abrasive rigid feedstock.
سهولة الوصول إلى الغرفة مع إمكانية الصيانة
Fast access to the cutting chamber simplifies blade inspection, cleaning, and servicing so
downtime stays under control.
سعة أكبر للأغراض الصلبة الكبيرة
This series is sized for larger feed and heavier production duty than light or medium
granulators, with reference capacities up to about 1200 kg/h.
حجم رقائق مُتحكم به مع شاشات قابلة للتبديل
Interchangeable mesh screens help maintain the target flake profile for downstream conveying,
washing, storage, or pelletizing.
تكامل التفريغ المرن
Support blower extraction, silo transfer, or bagging depending on your plant layout and the next
stage in the line.
التطبيقات المثالية للمُحَبِّبات الكبيرة جدًا
Best suited to large, hollow, thick-walled, or bulky rigid plastics
that are too awkward for smaller granulator platforms.
الحاويات الصناعية
Process HDPE drums, barrels, large bins, plastic crates, and
rigid transport packaging with more stable size reduction.
منصات بلاستيكية وقطع لوجستية ضخمة
A strong match for pallet recycling where large section sizes
and awkward geometry overload standard granulators.
قطع غيار السيارات والاستهلاكية
Handles bumpers, dashboards, child car seats, and other large
molded rigid plastic components.
الأنابيب، والقطاعات، وعمليات التنظيف السميكة
Suitable for large-diameter pipes, extruded profile scrap, and
heavy rigid lumps when the material still fits the granulator duty window.
سير عمل التحبيب للبلاستيك الصلب الكبير
A streamlined reduction sequence from bulky rigid feed to uniform
regrind.
تحميل المواد
Bulky rigid parts enter the machine manually or by conveyor
depending on the layout and feed size.
حبيبات باستخدام دوار القطع على شكل حرف V
The heavy-duty rotor and fixed knives shear the rigid
plastic into smaller pieces with stable cutting action.
حجم الإخراج المتحكم به
Material passes through the selected mesh screen only after
it reaches the required granule size.
استخراج ونقل
Blower suction, silo collection, or bagging handles the
finished regrind for storage or the next process stage.
لماذا تتفوق سلسلة المحببات الكبيرة جدًا على المحببات القياسية؟
The difference is not just motor size. Rotor geometry, chamber
openness, and overall build determine whether bulky rigid feed runs smoothly or constantly jams.
| ميزة | ستاندرد غرانيتولرز | سلسلة كبيرة جدًا |
|---|---|---|
| نافذة مقاسات المواد | أفضل للأشياء الصلبة الصغيرة | Handles bulky pallets, drums, crates, and large molded parts |
| معدل الإنتاج | انخفاض الإنتاج عند استخدام تغذية كبيرة الحجم | Up to about 1200 kg/h depending on material |
| مهام الشفرة والدوار | التآكل القياسي وقوة القطع | Heavy-duty V-cut rotor with premium D2 شفرات |
| استقرار العلف السائب | من المرجح أن يحدث تداخل أو اختناق | Better suited to awkward, hollow, and large rigid parts |
| الصيانة طويلة الأجل | مزيد من الانقطاعات في ظل ظروف العمل الشاقة | Easier chamber access and better wear tolerance |
المواصفات الفنية
Reference models for large rigid plastic granulation. Capacity is
application dependent and varies with screen size, material geometry, and wall thickness.
| نموذج | قوة المحرك | شفرات دوارة | شفرات ثابتة | حجم الغرفة | القدرة (كجم/ساعة) |
|---|---|---|---|---|---|
| SW-600 | 37 كيلو واط | 3 × 2 | 2 × 2 | 600 ملم | ~300 |
| SW-800 | 55 كيلو واط | 3 × 3 | 2 × 2 | 800 ملم | ~600 |
| برنامج SW-1000 | 75 كيلوواط | 3 × 3 | 2 × 2 | 1000 ملم | ~1000 |
| برنامج SW-1200 | 90 كيلو واط | 3 × 4 | 2 × 3 | 1200 ملم | ~1200 |
صور مرجعية
Machine views, feed examples, and typical granulated output for bulky
rigid plastic applications.
فيديو تشغيل الآلة
Watch the extra large granulator reduce bulky rigid plastic scrap into
line-ready regrind.
شهادات العملاء
Feedback from operations running large rigid plastic reduction at
industrial scale.
pallets. The throughput is exactly as promised.”
huge time-saver for our technicians.”
الأسئلة الشائعة التقنية
Answers to common sizing, maintenance, and material-fit questions for
large rigid plastic granulation.
A granulator uses high speed and sharp blades to cut plastic into small, uniform granules. It
is suitable for hollow or rigid items within the granulator duty window. A shredder uses
lower speed and higher torque for thicker or tougher material. For very thick rigid parts, a
shredder first is often the better choice.
The D2 blades can be removed for sharpening, and we recommend routine inspection based on
your material and operating hours. We also offer blade sharpening support for in-house
maintenance planning.
This series is optimized for rigid plastics. Soft films may require a different rotor setup
or a different machine category entirely. Share your material so we can recommend the right
configuration.
احصل على عرض سعر مخصص لحبيبات كبيرة الحجم للغاية
All machines include a 1-year limited warranty. Send us your material
type, part size, target throughput, and desired output size so we can recommend the right model.
