Granulación de alta resistencia para plásticos rígidos voluminosos.
Trituradora de plástico rígido resistente con abertura de alimentación extragrande
High-capacity granulator machines for large rigid plastics such as
pallets, drums, crates, car seats, and bulky molded parts. Choose from powerful models delivering
roughly 300 kg/h to 1200 kg/h depending on material and screen size.
Diseñado para obtener resultados de granulación de plástico rígido de gran tamaño.
This series is designed for processors who need to granulate oversized
rigid parts without relying on undersized standard granulators that jam, vibrate, or wear too
quickly.
Rotor de corte en V de amplia apertura para alimentación voluminosa
The open rotor with staggered V-cut claw blades improves bite, cutting force, and discharge flow
when processing large rigid plastic articles such as pallets, drums, and crates.
Cuchillas de acero para herramientas D2 de primera calidad
Heat-treated D2 blades support long cutting cycles, repeated sharpening, and dependable
performance on abrasive rigid feedstock.
Acceso a la cámara de fácil mantenimiento
Fast access to the cutting chamber simplifies blade inspection, cleaning, and servicing so
downtime stays under control.
Mayor capacidad para artículos rígidos de gran tamaño.
This series is sized for larger feed and heavier production duty than light or medium
granulators, with reference capacities up to about 1200 kg/h.
Tamaño de las escamas controlado con tamices intercambiables
Interchangeable mesh screens help maintain the target flake profile for downstream conveying,
washing, storage, or pelletizing.
Integración de descarga flexible
Support blower extraction, silo transfer, or bagging depending on your plant layout and the next
stage in the line.
Aplicaciones ideales para granuladores extragrandes
Best suited to large, hollow, thick-walled, or bulky rigid plastics
that are too awkward for smaller granulator platforms.
Contenedores industriales
Process HDPE drums, barrels, large bins, plastic crates, and
rigid transport packaging with more stable size reduction.
Palets de plástico y piezas logísticas voluminosas
A strong match for pallet recycling where large section sizes
and awkward geometry overload standard granulators.
Piezas de automóviles y de consumo
Handles bumpers, dashboards, child car seats, and other large
molded rigid plastic components.
Tuberías, perfiles y purgas gruesas
Suitable for large-diameter pipes, extruded profile scrap, and
heavy rigid lumps when the material still fits the granulator duty window.
Proceso de granulación para plásticos rígidos de gran tamaño
A streamlined reduction sequence from bulky rigid feed to uniform
regrind uniforme.
Material de carga
Bulky rigid parts enter the machine manually or by conveyor
depending on the layout and feed size.
Granulación con rotor de corte en V
The heavy-duty rotor and fixed knives shear the rigid
plastic into smaller pieces with stable cutting action.
Tamaño de salida de control
Material passes through the selected mesh screen only after
it reaches the required granule size.
Extracción y transferencia
Blower suction, silo collection, or bagging handles the
finished regrind for storage or the next process stage.
¿Por qué la serie extragrande supera a los granuladores estándar?
The difference is not just motor size. Rotor geometry, chamber
openness, and overall build determine whether bulky rigid feed runs smoothly or constantly jams.
| Característica | Granuladoras estándar | Serie extragrande |
|---|---|---|
| Ventana de tamaño del material | Más adecuado para artículos rígidos más pequeños. | Handles bulky pallets, drums, crates, and large molded parts |
| Rendimiento | Menor producción con piensos de gran tamaño. | Up to about 1200 kg/h depending on material |
| Servicio de palas y rotores | Desgaste estándar y fuerza de corte | Heavy-duty V-cut rotor with premium D2 cuchillas |
| Estabilidad de los piensos a granel | Es más probable que se forme un puente o se produzca un atasco. | Better suited to awkward, hollow, and large rigid parts |
| Mantenimiento a largo plazo | Mayor interrupción en condiciones de trabajo pesado. | Easier chamber access and better wear tolerance |
Especificaciones tecnicas
Reference models for large rigid plastic granulation. Capacity is
application dependent and varies with screen size, material geometry, and wall thickness.
| Modelo | Potencia del motor | Cuchillas giratorias | Cuchillas fijas | Tamaño de la cámara | Capacidad (kg/h) |
|---|---|---|---|---|---|
| SW-600 | 37 kW | 3 x 2 | 2 x 2 | 600 milímetros | ~300 |
| SW-800 | 55 kW | 3 x 3 | 2 x 2 | 800 milímetros | ~600 |
| SW-1000 | 75 kW | 3 x 3 | 2 x 2 | 1000 milímetros | ~1000 |
| SW-1200 | 90 kW | 3 x 4 | 2 x 3 | 1200 milímetros | ~1200 |
Imágenes de referencia
Machine views, feed examples, and typical granulated output for bulky
rigid plastic applications.
Vídeo de funcionamiento de la máquina
Watch the extra large granulator reduce bulky rigid plastic scrap into
line-ready regrind.
Testimonios de clientes
Feedback from operations running large rigid plastic reduction at
industrial scale.
pallets. The throughput is exactly as promised.”
huge time-saver for our technicians.”
Preguntas técnicas frecuentes
Answers to common sizing, maintenance, and material-fit questions for
large rigid plastic granulation.
A granulator uses high speed and sharp blades to cut plastic into small, uniform granules. It
is suitable for hollow or rigid items within the granulator duty window. A shredder uses
lower speed and higher torque for thicker or tougher material. For very thick rigid parts, a
shredder first is often the better choice.
The D2 blades can be removed for sharpening, and we recommend routine inspection based on
your material and operating hours. We also offer blade sharpening support for in-house
maintenance planning.
This series is optimized for rigid plastics. Soft films may require a different rotor setup
or a different machine category entirely. Share your material so we can recommend the right
configuration.
Obtenga un presupuesto personalizado para granulación extragrande.
All machines include a 1-year limited warranty. Send us your material
type, part size, target throughput, and desired output size so we can recommend the right model.
