Granulação de alta resistência para plásticos rígidos e volumosos.
Triturador de plástico rígido para serviço pesado com abertura de alimentação extra-grande
High-capacity granulator machines for large rigid plastics such as
pallets, drums, crates, car seats, and bulky molded parts. Choose from powerful models delivering
roughly 300 kg/h to 1200 kg/h depending on material and screen size.
Projetado para grandes volumes de granulação de plástico rígido.
This series is designed for processors who need to granulate oversized
rigid parts without relying on undersized standard granulators that jam, vibrate, or wear too
quickly.
Rotor de corte em V totalmente aberto para alimentação volumosa
The open rotor with staggered V-cut claw blades improves bite, cutting force, and discharge flow
when processing large rigid plastic articles such as pallets, drums, and crates.
Lâminas de aço ferramenta D2 premium
Heat-treated D2 blades support long cutting cycles, repeated sharpening, and dependable
performance on abrasive rigid feedstock.
Acesso à câmara facilitando a manutenção
Fast access to the cutting chamber simplifies blade inspection, cleaning, and servicing so
downtime stays under control.
Maior capacidade para itens rígidos de grande porte
This series is sized for larger feed and heavier production duty than light or medium
granulators, with reference capacities up to about 1200 kg/h.
Tamanho de flocos controlado com telas intercambiáveis
Interchangeable mesh screens help maintain the target flake profile for downstream conveying,
washing, storage, or pelletizing.
Integração de descarga flexível
Support blower extraction, silo transfer, or bagging depending on your plant layout and the next
stage in the line.
Aplicações ideais para granuladores extragrandes
Best suited to large, hollow, thick-walled, or bulky rigid plastics
that are too awkward for smaller granulator platforms.
Contêineres Industriais
Process HDPE drums, barrels, large bins, plastic crates, and
rigid transport packaging with more stable size reduction.
Paletes de plástico e peças volumosas para logística
A strong match for pallet recycling where large section sizes
and awkward geometry overload standard granulators.
Peças automotivas e de consumo
Handles bumpers, dashboards, child car seats, and other large
molded rigid plastic components.
Tubos, perfis e purgas espessas
Suitable for large-diameter pipes, extruded profile scrap, and
heavy rigid lumps when the material still fits the granulator duty window.
Fluxograma de Granulação para Plásticos Rígidos de Grande Porte
A streamlined reduction sequence from bulky rigid feed to uniform
regrind.
Carregar material
Bulky rigid parts enter the machine manually or by conveyor
depending on the layout and feed size.
Granular com rotor de corte em V
The heavy-duty rotor and fixed knives shear the rigid
plastic into smaller pieces with stable cutting action.
Tamanho da saída de controle
Material passes through the selected mesh screen only after
it reaches the required granule size.
Extrair e transferir
Blower suction, silo collection, or bagging handles the
finished regrind for storage or the next process stage.
Por que a Série Extra Grande supera os granuladores padrão?
The difference is not just motor size. Rotor geometry, chamber
openness, and overall build determine whether bulky rigid feed runs smoothly or constantly jams.
| Recurso | Granuladores padrão | Série Extra Grande |
|---|---|---|
| Tamanho do material da janela | Melhor para itens rígidos menores. | Handles bulky pallets, drums, crates, and large molded parts |
| Taxa de transferência | Menor produção com ração de tamanho excessivo. | Up to about 1200 kg/h depending on material |
| Serviço de lâmina e rotor | Força de corte e desgaste padrão | Heavy-duty V-cut rotor with premium D2 lâminas |
| Estabilidade da ração a granel | É mais provável que forme ponte ou congestionamento. | Better suited to awkward, hollow, and large rigid parts |
| Manutenção de longo prazo | Mais interrupções sob carga pesada | Easier chamber access and better wear tolerance |
Especificacoes tecnicas
Reference models for large rigid plastic granulation. Capacity is
application dependent and varies with screen size, material geometry, and wall thickness.
| Modelo | Potência do motor | Lâminas rotativas | Lâminas fixas | Tamanho da câmara | Capacidade (kg/h) |
|---|---|---|---|---|---|
| SW-600 | 37 kW | 3 x 2 | 2 x 2 | 600 milímetros | ~300 |
| SW-800 | 55 kW | 3 x 3 | 2 x 2 | 800 milímetros | ~600 |
| SW-1000 | 75 kW | 3 x 3 | 2 x 2 | 1000 milímetros | ~1000 |
| SW-1200 | 90 kW | 3 x 4 | 2 x 3 | 1200 milímetros | ~1200 |
Imagens de referência
Machine views, feed examples, and typical granulated output for bulky
rigid plastic applications.
Vídeo de operação da máquina
Watch the extra large granulator reduce bulky rigid plastic scrap into
line-ready regrind.
Depoimentos de clientes
Feedback from operations running large rigid plastic reduction at
industrial scale.
pallets. The throughput is exactly as promised.”
huge time-saver for our technicians.”
Perguntas frequentes técnicas
Answers to common sizing, maintenance, and material-fit questions for
large rigid plastic granulation.
A granulator uses high speed and sharp blades to cut plastic into small, uniform granules. It
is suitable for hollow or rigid items within the granulator duty window. A shredder uses
lower speed and higher torque for thicker or tougher material. For very thick rigid parts, a
shredder first is often the better choice.
The D2 blades can be removed for sharpening, and we recommend routine inspection based on
your material and operating hours. We also offer blade sharpening support for in-house
maintenance planning.
This series is optimized for rigid plastics. Soft films may require a different rotor setup
or a different machine category entirely. Share your material so we can recommend the right
configuration.
Solicite um orçamento personalizado para granulação extra grande.
All machines include a 1-year limited warranty. Send us your material
type, part size, target throughput, and desired output size so we can recommend the right model.
