Soft Material & Film Single-Shaft Shredder
The ultimate solution for efficiently processing a wide range of soft materials and films, turning waste into value.
Get a QuoteCore Advantages
High Efficiency
Unique feeding mechanism prevents jamming and ensures continuous, high-throughput shredding.
Enhanced Capacity
A large diameter spindle maximizes material contact, significantly boosting production capacity.
Durable & Stable
Advanced coupling reduces vibration, extending the life of the spindle and reducer for reliable operation.
Automated Control
Fully automated PLC system with overload protection for safe, stable, and labor-saving performance.
How It Works
1. Material Feeding
Load various soft materials like films, bags, and fibers into the shredder’s bin.
2. Precision Shredding
The single-shaft rotor with specialized knives efficiently cuts and sizes the material.
3. Uniform Output
Shredded material is discharged, ready for the next stage of recycling or processing.
Application Scenarios
Plastic Film & Packaging
Efficiently process post-industrial and post-consumer films (PE, PP, BOPP) into uniform flakes for washing and pelletizing lines.
Woven & Bulk Bags
Ideal for shredding contaminated or used woven PP bags and bulk bags (FIBCs) into manageable pieces for further recycling.
Textiles & Fibers
Process industrial waste cloth, PET chemical fibers, and other textiles, preparing them for fiber reclamation or alternative fuel production.
Features & Technical Specifications
Innovative Feeding Mechanism
Experience hassle-free shredding with our unique bin design that facilitates overall circular movement, allowing for unlimited feeding and high shredding efficiency without the risk of jamming.
Precision Cutting Technology
Dual fixed knives, positioned above and below the spindle, effectively slice through materials, preventing them from wrapping around the shaft and achieving the desired crushed size.
| Shredder model | Shaft diameter (mm) | Moving knife qty. | Fixed knife qty. | Max. capacity (kg/h) | Motor power (KW) | Feeding mouth (L x W) | Host weight (kg) | Dimensions (L x W x H) |
|---|---|---|---|---|---|---|---|---|
| L2455 | 300 | 24 | 2 | 400 | 22 | 800 x 1300 | 3600 | 3250 x 1500 x 2350 |
| L3063 | 300 | 30 | 2 | 550 | 30 | 900 x 1300 | 4000 | 3250 x 1750 x 2350 |
| L3980 | 350 | 39 | 2 | 750 | 45 | 1100 x 1500 | 6000 | 4150 x 1900 x 2450 |
| L36100 | 400 | 36 | 2 | 1200 | 55 | 1300 x 1800 | 8000 | 4700 x 2550 x 2650 |
| L42120 | 400 | 42 | 2 | 1500 | 75 | 1500 x 1900 | 9500 | 5350 x 2850 x 2760 |
Device Showcase
Watch It in Action
Get a Custom Solution & Quote
Contact us today to discuss your specific needs. Our experts will provide you with a tailored solution and a competitive quote.
Frequently Asked Questions
What types of materials can this shredder handle?
It is ideal for a wide range of soft materials, including PE/PP films, woven bags, tonnage bags, industrial waste cloth, domestic garbage, and PET chemical fibers.
How does the machine prevent material from wrapping around the shaft?
Our design incorporates dual fixed knives positioned strategically above and below the main spindle. This configuration ensures materials are sliced cleanly rather than getting tangled, guaranteeing smooth operation.
Is the operation fully automatic?
Yes, the shredder is controlled by a PLC system, enabling fully automatic functions like start, stop, reverse, and automatic overload protection. This significantly reduces labor costs and enhances safety.
What is the lead time after placing an order?
Lead times vary depending on the model and customization requirements. Please contact us through the inquiry form for a precise delivery schedule based on your order.
